Explosion-Proof Industrial Floor Scale 48x48 - NTEP Certified, Intrinsically Safe SL 4x4 by SellEton - Perfect for Hazardous Work Environments & Chemical Plants

Are you facing challenges in accurately weighing materials in potentially explosive environments?

The SellEton SL-4x4-Explosion Proof Industrial Floor Scale, complete with the SL-7510-SS-C-EX Intrinsically Safe Indicator, is your ultimate solution. Designed for uncompromised safety and accuracy, this intrinsically safe NTEP-certified floor scale offers reliability in hazardous areas where chemical or gaseous substances pose a risk.

Key Benefits:

• Certified Safety: NTEP is approved for 5,000 divisions and intrinsically safe for use in explosive environments, ensuring your operations meet rigorous safety standards.
• Flexible Power Options: Features a stainless steel NEMA 4X enclosure with dual power options – a removable rechargeable battery and a power adapter with a 47 ft long charging cord. This versatility ensures continuous operation, even in areas without immediate access to power outlets.
• Versatile Weighing Functions: Equipped with multiple weighing units and functions such as accumulation, counting, gross, tare, zero, and hold options, enhancing functionality and adaptability to various industrial needs.
• Enhanced Readability: The easy-to-read, 1” tall ultra-bright LED screen allows clear visibility in any working condition.
• User-Friendly Interface: The interface simplifies operation with straightforward navigation through its various modes, including Gross, Count, and Accumulation.
• Versatile and Reliable Power: Features multiple weighing units (lb/kg for LED; g/oz/for LCD) and is powered by a rechargeable battery via the , ensuring continuous and adaptable operation.
• NTEP Certified (Legal for trade): COC # 22-056

Key Features of the SL-7510-SS-C-EX Indicator:

• Robust Design: Encased in durable stainless steel, suitable for industrial environments.
• Comprehensive Power Options: Includes an AC adapter and a rechargeable battery for uninterrupted operation.
• Flexible Weighing Units: Multiple units (lb/kg; g/oz/lb on LCD only) are offered for diverse weighing needs.
• Advanced Weighing Functions: Features Gross, Tare, Pre-Set Tare, Zero, and multiple Hold functions for tailored usage.
• Safety Alarms: Equipped with overload/underload alarms and an automatic error warning to maintain operational integrity.
• Energy Efficient: Includes a power-saving mode to extend battery life.
• Geographical Adaptation: Allows modification of gravity settings based on different geographical locations.
• Precision Control: Offers 100% manual zero range setting for high accuracy.
• Enhanced Visibility: 1” LED or LCD display with backlight ensures clear readability.
• Connectivity Options: Capable of connecting to a remote display and a printer for versatile data management.
• Regulatory Compliance: NTEP approved for 5,000 divisions, ensuring reliability and accuracy.
• High Resolution: Capable of displaying up to 50,000 graduations for precise measurements.
• Installation Ready: Comes with a mounting bracket and hardware for easy setup.
• Versatile Interface: Features a Full Duplex RS-232 Serial Port for extended connectivity.
• Load Cell Compatibility: Drives up to 6 350 Ohm load cells, supporting a range of configurations.
• Splash-Proof Components: Splash-proof keyboard and display enhance durability in moist or dusty conditions.

Indicator Specifications:

• Display: LCD, 1.5 inch, 6-digit numeric
• Units of Measure: Primary (lb, kg); Secondary (oz, g)
• Accuracy Class: 5000 e
• Resolution: 120,000 divisions (dd) for industrial use; 10,000 dd HB44
• Excitation Voltage: 5V DC
• Maximum Output Current: 120 mA
• Excitation Circuit: 5 VDC, 4 wire connections
• Load Cell Compatibility: Supports up to 6 load cells of 350 Ω maximum each
• Load Cell Excitation: 5 ± 0.5VDC
• Zero Stability Error: TKspn < ± 6 ppm//K
• Sensitivity (Internal): 0.3 μV / d
• Input Voltage Range: -30 to +30mV DC
• Power Supply: 100~240VAC @ 50/60Hz
• Power Consumption: 5W @9VDC
• Operating Temperature Range: 14 °F to 104 °F (-10 °C to +40 °C)
• Weight: 4.3 lbs (1.95 kg)
• Internal Resolution: 24 bit A/D Sigma-Delta; 1,048,000 d
• Display Resolution: 120,000 dd industrial; 10,000 dd HB44
• Display Increment: Selectable 1, 2, 5, 10, 20, 50
• Decimal Point: Selectable 0, 1, 2, 3, 4 decimal places
• Conversion Rate: 12 samples per second (typical)
• Analog Signal Input Range: 1mV/V to 3mV/V
• Analog Signal Sensitivity: 0.1 uV/graduation (min)
• Measurement Rate: 0~15mV
• Auto Zero Tracking: 0 - 5 dd increments
• Auto Zero Delay: 0 - 3 second increments
• Motion Detection: 1 - 10 dd
• Motion Delay: 0 - 55 dd


Customization Options for the SL-800-Series Floor Scale

Enhance your operations with a range of add-on features designed to meet your specific needs:

• Printer Integration: Easily attach a  for instant weight documentation, streamlining record-keeping processes.

• Scoreboard Options: Opt from  for superior visibility, allowing distant viewing of weight data beyond the standard LCD indicator.

• Pit-Frame Installation: Choose between a permanent,  installation or versatile  for flexible placement.

• Data Collection Software: Utilize our  to track and manage weight records efficiently and efficiently.

• Ramp Access: Implement optional to facilitate simple and safe loading and unloading using carts or .

• Indicator Stands: Select from  to ensure your indicator is optimally positioned for ease of use and visibility.

• Explosion-Proof Indicator: Equip your scale for use in intrinsically safe environments with our , preventing ignition in explosive atmospheres.

• Water-Resistant Upgrades: Enhance your scale's resilience in outdoor or moist conditions, ensuring continuous performance and durability.

• Bumper Guards: Install bumper guards to shield your scale from accidental impacts with forklifts or other heavy machinery.

• Output Options: Choose from 4-20mA or 0-5V relay outputs to seamlessly integrate with existing systems for enhanced data communication.

Custom Manufacturing

If you require custom-made scales, SellEton Scales can manufacture scales in any size using carbon steel, galvanized steel, stainless steel, and aluminum.

Choosing the SellEton SL-4x4 Explosion-Proof Industrial Floor Scale elevates your facility’s safety standards while ensuring precise measurements. Ideal for environments where safety cannot be compromised, this scale provides peace of mind with its robust design and reliable performance. Imagine the confidence and efficiency you will gain, knowing that your weighing processes are secure and accurate, enabling you to focus on productivity without safety concerns. Invest in the SellEton SL-4x4 today and transform how you handle hazardous material weighing.

Please contact our sales team for more information or to discuss your specific requirements. We're here to help you find the perfect weighing solution for your industrial needs.

Attention:

If you plan to use the scale outdoors, it is essential to have a Stainless Steel indicator, Stainless steel Load cells & Stainless steel junction box. This ensures rust resistance and minimizes errors in readings caused by environmental factors.

Please note that our scales are not waterproof "AS IS." However, we offer an upgrade option to make them suitable for rainy or humid regions. This upgrade ensures reliable performance and longevity.
