| Power Input |
| 115 or 230 VAC, 50/60 Hz | Internal rechargeable lithium battery |
| Battery Life |
| N/A | Up to 60 hours (1 x 350Ω), 40 hours (4 x 350Ω) |
| Excitation Voltage |
| 5 VDC, 4 × 350Ω or 8 × 700Ω load cells | 5 VDC, 4 × 350Ω or 8 × 700Ω load cells |
| Analog Signal Input Range |
| -0.6 mV/V to 3.0 mV/V | -0.6 mV/V to 3.0 mV/V |
| Analog Signal Sensitivity |
| 0.3 μV/graduation min, 1.5 μV/grad recommended | 0.3 μV/graduation min, 1.5 μV/grad recommended |
| A/D Sample Rate |
| 3 to 30 Hz (software selectable) | 30 Hz |
| Resolution |
| Internal: 1,000,000 counts, Display: 10,000 | Internal: 1,000,000 counts, Display: 10,000 |
| System Linearity |
| Within 0.01% of full scale | Within 0.01% of full scale |
| Digital I/O (Optional) |
| N/A | Requires option card (24V source, 3 digital inputs, 2 digital outputs) |
| Circuit Protection |
| RFI, EMI, ESD protection | RFI, EMI, ESD protection |
| Load Cell Connection |
| Cord grip entry (optional detachable plug) | Cord grip entry (optional detachable plug) |
| Communication Ports |
| RS-232 (Full Duplex EDP Port), Printer Port (RS-232 or 20mA) | RS-232 (Full Duplex EDP Port), Printer Port (RS-232 or 20mA) |
| Baud Rates |
| 300 - 9600 bps, 7 or 8 data bits, even/odd/no parity | 300 - 9600 bps, 7 or 8 data bits, even/odd/no parity |
| Annunciators |
| Center of zero, standstill, gross, net, lb, kg, oz, g | Center of zero, standstill, gross, net, lb, kg, oz, g, battery, setpoints 1 & 2, Hold |
| Display |
| 0.8 in (20 mm) Red LED, 6-digit, seven-segment | 0.8 in (20 mm) LCD with backlight, 6-digit, seven-segment |
| Keys/Buttons |
| Five-key tactile membrane panel | Numeric keypad (0-9), Zero, Tare, Preset Tare, Hold, Gross/Net, Units, Clear, Enter/Print |
| Operating Temperature |
| 14°F to 122°F (-10°C to 50°C) | 14°F to 122°F (-10°C to 50°C) |
| Material & Rating |
| Heavy gauge ABS | Heavy gauge ABS |
| Weight |
| 2.6 lb (1.2 kg) | 2.6 lb (1.2 kg) |
| Warranty |
| One-year limited | One-year limited |
| Approvals |
| NTEP CC 03-059, Class III/IIIL 10,000d, Measurement Canada AM-5517, CE Marked | NTEP CC 03-059, Class III/IIIL 10,000d, Measurement Canada AM-5517, CE Marked |
